06 Channel ECG machine – ECG-1106G

Origin: China

(Thermal Printer, Japan & Mother board Accessories, Germany)

Technical Specification:

Safety Standard: IEC Class I, type CF

Acquisition: 12 Lead acquisition simultaneously

Input Circuit: Floating, protection against defibrillator and pacemaker

A/D Converter: 12 bit

Time Constant: ≥3.2s

Frequency Response: 0.05Hz  ̴  165 Hz

Sensitivity: 2.5, 5, 10, 20, 40 (mm/mV), Auto

Input Impedance: ≥50MΩ

Input Circuit Current: ≤50nA

Calibration Voltage: 1mV±2%

Noise Level: <15µVp-p

Anti Baseline Drift: Automatic

Filter:   EMG Filter: 35 Hz  ̴  45 Hz (-3db)

ADS Filter: Auto (0.15-0.50Hz)

HUM Filter: 50Hz/60Hz (-20dB)

CMRR: >100dB

Patient Current Leakage: <10µA

Paper Speed: 6.25/12.5/25/50mm/s

Recording Paper: 63mm/80mm(width), 20m/30(length), roll

Power Supply: AC: 110/220V, 50/60Hz, 85V  ̴  265V (option)

DC:14.4V, built- in rechargeable lithium battery

Dimension: 345mm x 300mm x 80mm, 415mm x 195mm x 380mm(carton)

Net Weight: 2.5kgs

Gross Weight: 4.5kgs
