Hand Held Pulse Oximeter – NT-1D

Origin: U.S.A

Technical Specification:

SpO2: Measurement Range: 0~100%

Accuracy: +2% during 70%~100%

0%~69% unspecified
Pulse Rate:

Measurement Range:30bpm~250bpm

Accuracy: 1bpm or ±2%

Whichever is greater

EtCO2: Measurement Range: 0~150mmHg Resolution: 0.1 mmHg (0-69)mmHg

0.25mmHg (70~150)mmHg

Accuracy: ±2mmHg (0~40)mmHg

±5% (41~70) mmHg

±8%(71-100) mmHg

±10% (101-105)mmHg

Respiration Rate:
Measurement Range： 0~150bmp
Accuracy： ±1bmp
Alarm:
Three levels of visual, audio alarms

whichever is greater
Data Transmission:
Power Requirements: DC: 9V 700mA

Four Standard “AA”” size batteries or rechargeable batteries.

Battery Capacity: ≥12 Hours (SpO2 Only)

Battery Capacity: ≥5 hours (SpO2+CO2)

Environment:
Operating Temperature: 0◦C~50◦C
Humidity: ≤95%
Altitude: -390m~5,000m
Transport/Storage Temperature: -20◦C~70◦C
Humidity:≤95%
Physical Characteristics:
Dimensions: 73mm (W) x127mm (H) x 23mm (D)
Maximum Weight: 500g
